TD-W8968 300Mbps Wireless N USB ADSL2+ Modem Router User Guide
102
Double-click Internet
Protocol Version 4
(TCP/IPv4)
Select Obtain DNS server
address automatically
Select Obtain an IP address
automatically
Click OK
