User Name

: Enter the User Name here.

User Type: Select the type for the User.

 Local User: Indicates that the user is connected to a

local SNMP engine.

 Remote User: Indicates that the user is connected to a

remote SNMP engine.

Group Name: Select the Group Name of the User. The User is classified to

the corresponding Group according to its Group Name,

Security Model and Security Level.

Security Model: Select the Security Model for the User.

Security Level: Select the Security Level for the SNMP v3 User.

Auth Mode: Select the Authentication Mode for the SNMP v3 User.

 None: No authentication method is used.

 MD5: The port authentication is performed via

HMAC-MD5 algorithm.

 SHA: The port authentication is performed via

SHA

(Secure Hash Algorithm)

. This authentication mode has a

higher security than MD5 mode.

Auth Password: Enter the password for authentication.

Privacy Mode: Select the Privacy Mode for the SNMP v3 User.

 None: No privacy method is used.

 DES: DES encryption method is used.

Privacy Password: Enter the Privacy Password.

 User Table

Select: Select the desired entry to delete the corresponding User. It is

multi-optional.

User Name: Displays the name of the User.

User Type: Displays the User Type.

Group Name: Displays the Group Name of the User.

Security Model: Displays the Security Model of the User.

Security Level: Displays the Security Level of the User.

Auth Mode: Displays the Authentication Mode of the User.

Privacy Mode: Displays the Privacy Mode of the User.

Operation: Click the Edit button to modify the Group of the User and click

the Modify button to apply.

Note:

The SNMP User and its Group should have the same Security Model and Security Level.

10.1.5 SNMP Community

SNMP v1 and SNMP v2c adopt community name authentication. The community name can limit

access to the SNMP agent from SNMP network management station, functioning as a password. If
