Bosch Tronic 3000 С ED 18-2S [8/18] Specifications

8 | RU

6 720 643 236 (2010/02)

Specifications

Rated power (kW) 13.2 18 24

Rated voltage 400V3~ 400V3~ 400V3~

Economy setting e [kW]

1st stage - 6 8

2nd stage 8,8 12 16

Intensive setting II [kW]

1st stage - 9 12

2nd stage 13,2 18 24

Switch-on point [I/min]

1st stage - 4,0 5,0

2nd stage 3,6 5,0 6,6

Mixed water [I/min] at rated power

approx. 38 °C 7,3 9,9 13,2

approx. 50 °C

(supply temperature 12 °C)

5,0 6,8 9,1

Minimum flow pressure of appliance

[MPa (bar)]

1) Plus any pressure loss at the tap mixer

with flow limiter 0,03 (0,3) 0,07 (0,7) 0,09 (0,9)

without flow limiter 0,02 (0,2) 0,04 (0,4) 0,06 (0,6)

Operative range in waters of specific electric

resistance at 15 °C [ Wcm]

≥ 1300 ≥ 1300 ≥ 1300

Rated pressure

[MPa (bar)]

1 (10) 1 (10) 1 (10)

Maximum permissible

supply temperature [ °C]

20 20 20

Tab. 3
