-14-

port sketch.

Note:

1) By default, TL-ER5120 is set to work in the mode of dual WAN ports.

2) Any change to the number of WAN ports may lead to a loss of current configurations. Please be

sure to backup your configurations in advance.

3) The DMZ port will not be available if four WAN ports are enabled.

3.1.3.2 WAN1

TL-ER5120 provides the following six Internet connection types: Static IP, Dynamic IP, PPPoE/Russian

PPPoE, L2TP/Russian L2TP, PPTP/Russian PPTP and BigPond. To configure the WAN, please first

select the type of Internet connection provided by your ISP (Internet Service Provider).

Tips:

● It’s allowed to set the IP addresses of multiple WAN ports within the same subnet. However, to

guarantee a normal communication, make sure that the WAN ports can access the same network,

such as Internet or a local area network.

● The amount of tab pages for WAN port varies with the number of the WAN ports. For the

configurations of the other WAN ports, please refer to the instructions of WAN1.

Choose the menu Network→WAN→WAN1 to load the configuration page.

1) Static IP

If a static IP address has been provided by your ISP, please choose the Static IP connection type to

configure the parameters for WAN port manually.
