Tp-Link TL-WN422G [9/46] Overview of the product
![Tp-Link TL-WN422G [9/46] Overview of the product](/views2/1004442/page9/bg9.png)
TL-WN422G High-Gain Wireless USB Adapter User Guide
2
Chapter 1. Introduction
Thank you for choosing TL-WN422G High-Gain Wireless USB Adapter.
1.1 Overview of the product
The adapter is a USB 2.0 pen-size wireless adapter supporting IEEE 802.11b/g 2.4GHz radio
operation. It provides high-speed wireless connection with data rate up to 54Mbps, and wireless
roaming allows the user to move among different AP without losing the current connection. The
adapter provides excellent security features, including TKIP, AES, WPA, and up to 256 bit WEP
encryption security, which makes the network almost impenetrable.
Featuring high performance of fast transmission rates, simple installation and adaptability, as well
as strong security, the TL-WN422G High-Gain Wireless USB Adapter is the perfect solution for
personal and small business use.
1.2 Feature
¾ Complies with IEEE 802.11b and IEEE 802.11g Standards
¾ Provides 64/128/256 bit WEP Encryption
¾ Supports WPA, WPA2, IEEE 802.1X, TKIP, AES
¾ Supports 54/48/36/24/18/12/9/6Mbps or 11/5.5/2/1Mbps wireless LAN data transfer rates
¾
USB 2.0 interface and compatible with USB 1.1
¾ High Speed Data Rate Up to 54Mbps
¾ Supports Windows 98, ME, 2000, XP, 2003, Vista and Windows 7
¾ Simulates AP Mode, And Supports PSP connection
1.3 LED Status
The TL-WN422G High-Gain Wireless USB Adapter has a LED indicator.
LED Indicator:
Status Working Status
Off The driver has not been installed.
Flashing Slowly
The driver has been installed but there is no data being transmitted
or received.
Flashing Quickly There is data being transmitted or received.
