10/100 Auto Negotiation Switch User’s Guide
Managing the DES-3224
46
Follow these steps to configure the SNMP Trap Manager Setting:
1.
Enter the IP Address of the Trap Manager.
2.
Enter the name of the SNMP Community String.
3.
Select Status and toggle the space bar to select Valid or Invalid.
4.
Select Save and press Enter.
