D-Link DES-3224 [75/75] 100 auto negotiation switch user s guide
![D-Link DFE-904 [75/75] 100 auto negotiation switch user s guide](/views2/1043060/page75/bg4b.png)
10/100 Auto Negotiation Switch User’s Guide
DES-3224 Technical Specifications
65
S
Side Panels..........................................................3
SNMP Community.......................................44, 45
SNMP Management.................................4, 21, 43
SNMP Setting....................................................44
SNMP Trap .......................................................45
Software Update..........................................22, 30
Software Version...............................................23
Spanning Tree....................................................20
Spanning Tree Alg.............................................41
Spanning Tree Config........................................40
Spanning Tree Config........................................40
STA Operation ..................................................40
State..................................................................38
Status .........................................35, 44, 45, 49, 54
Store and Forward..............................................28
Super User.........................................................34
Switch Port Configuration..................................38
System Configuration ........................................20
System Configuration Menu...............................21
System Contact..................................................24
System Description............................................24
System Information............................................22
System Information Menu..................................23
System Location ................................................24
System Name.....................................................24
System Rate Control....................................22, 28
System Reset...............................................22, 25
T
Telnet............................................................4, 16
TrunkGroup.................................................49, 54
Trunking Port ....................................................55
Trunking Port Management..........................21, 53
Trunking Port Name..........................................56
U
Unpacking...........................................................6
User Account Change........................................33
User Account Management..........................20, 33
User Name.............................................34, 35, 37
Utilization .........................................................14
V
Virtual LAN Name............................................51
VLAN...............................................................47
VLAN Name.....................................................50
VLAN Port........................................................47
VLAN Port Management...................................21
