ABOUT THIS GUIDE
Congratulations on your purchase of the Web Smart 48+2G-Port 10/100/1000Mbps/SFP Switch. This device integrates 1000Mbps
Gigabit Ethernet, 100Mbps Fast Ethernet, and 10Mbps Ethernet network capabilities in a highly flexible package.
Purpose
This guide discusses how to install your Web Smart 48+2G-Port 10/100/1000Mbps/SFP Switch.
Terms/Usage
In this guide, the term “Switch” (first letter upper case) refers to your Web Smart 48+2G-Port 10/100/1000Mbps Switch, and “switch”
(first letter lower case) refers to other Ethernet switches.
