Technical Data
Fluke 789
ProcessMeter
™
1000V
CAT III
Designed and
Conforms to
IEC 1010-1
LISTED
950 Z
R
N10140
Double your power.
The Fluke 787 ProcessMeter was the
first tool to combine a loop calibrator
with a DMM to give process technicians
double the power in one tool. Now
it’s even better—the ultimate loop
calibration multimeter—the Fluke 789
ProcessMeter.
The 789 has a display that’s not only
twice as large, but also twice as bright
with two levels of backlighting. And
with its built-in, selectable
250 ohm HART
®
resistor, it eliminates
the need to carry a separate resistor
with you.
Now process technicians can do a lot
more while carrying a lot less.
Key new features of the Fluke 789
•
24 V Loop power supply
•
HART mode setting with loop power (adds 250
ohm resistor)
•
100 % larger dual display
•
1200 ohm drive capability on mA source
•
Enhanced backlight with two brightness
settings
•
0 % to 100 % mA Span Check buttons to
toggle between 4 and 20 mA
•
Infrared I/O serial port compatible with
FlukeView
®
Forms Software Version 2.1
•
Externally accessible fuses for easy replace-
ment
These 787 features are also included in the 789
•
DMM designed to meet 1000 volt IEC 1010
CAT III standards
•
Precision 1000 V, 440 mA true-rms digital
multimeter
•
Frequency measurement to 20 kHz
•
Min/Max/Average/Hold/Relative modes
•
Diode test and continuity beeper
•
Simultaneous mA and % of scale readout
•
20 mA dc current source / loop calibrator /
simulator
•
Manual step (100 %, 25 %, Coarse, Fine) plus
Auto Step and Auto Ramp
•
Externally accessible battery for easy battery
changes
Содержание
- Double your power 1
- Fluke 789 processmeter 1
- Technical data 1
- 1 7 in h x 3 4 in w x 8 0 in l weight 600 g 1 lbs battery four aa alkaline batteries battery life 140 hours typical measurement 10 hours typical sourcing 12 ma warranty 3 years 2
- C relative humidity 95 up to 30 c 75 up to 40 c 45 up to 50 c 35 up to 55 c vibration random 2 g 5 500 hz shock 1 meter drop test safety designed in accordance with en61010 ansi isa s82 1 1994 and can csa c22 no 1010 92 over voltage category iii size 2
- General specifications 2
- Mm h x 100 mm w x 203 mm l 2
- Model fluke 789 processmeter including tl71 premium test lead set plus ac72 alligator clips four aa alkaline batteries installed users manual and quick reference guide 2
- Optional accessories 2
- Ordering information 2
- T ir infrared temperature probe 80tk thermocouple module 80t 150u universal temperature probe tl20 tl22 tl24 tl26 tl28 tl40a test lead sets ac20 ac80 clips tp20 industrial test probes 80i 400 ac current clamp i 410 ac dc current clamp i 1010 ac dc current clamp c25 c100 cases 80k 6 and 80k 40 high voltage probes 85rf high frequency probes pv350 pressure vacuum module fiber optic meter fom lpak80 4 lockpak tpak toolpak meter hanging kit 2
