Fluke 715 mA Loop
Calibrators
Technical Data
Fluke 715 Volt/mA Calibrator
Volt Milliamp Calibrator to troubleshoot process loops
The Fluke 715 Volt/mA Calibrator delivers outstanding performance,
durability and reliability. Offered in the rugged Fluke 80 Series DMM
package, the calibrator is compact, lightweight and easy to carry. With
a push button interface similar to the multifunction Fluke 740 Series
Documenting Process Calibrators, the 715 is easy to use. It is EMI toler
-
ant, dust/splash resistant and features a removable battery door for
quick battery changes. It features:
•
Measure loop current (0 mA to 20 mA, 4 mA to 20 mA) signals
with 0.01 %
accuracy and 0.001 mA resolution
•
Source precision voltage signals up to 20 V with 0.01 % accuracy
•
Measure voltage output process signals from PLCs, transmitters
•
Source or simulate 24 mA loop current
•
24 V loop supply with simultaneous current measurement
Fluke 707 Loop Calibrator
The fastest, one-handed tool for loop checks
The Fluke 707 Loop Calibrator is a high performance solution for
calibration, repair and maintenance of current loops. The “Quick Click”
knob makes it extremely fast and easy to use. It features:
•
One handed user interface with “Quick Click” detented knob
•
mA sourcing, simulation and measurement
•
0.015 % accuracy and 0.001 mA resolution
•
Simultaneous mA and % of span display
•
Selectable step or ramp outputs
•
24 V Loop supply with mA measure, including 250 Ω HART resistor
•
0 V dc to 28 V dc measurement to check Loop Voltage
•
Removable battery door for quick battery replacement
•
Compact case with protective holster
•
Three year warranty
Fluke 705 Loop Calibrator
Low cost calibration muscle
The Fluke 705 Loop Calibrator is a cost-effective, integrated solution for
calibration, repair and maintenance of current loops. It features:
•
mA sourcing, simulation and measurement
•
0.02 % accuracy and 0.001 mA resolution
•
Simultaneous mA and % of span display
•
Selectable step or ramp outputs
•
24 V Loop supply with mA measure
•
0 V dc to 28 V dc measurement to check Loop Voltage
•
Removable battery door for quick battery replacement
•
Compact case with protective holster
•
Three-year warranty
Содержание
- Fluke 705 loop calibrator 1
- Fluke 707 loop calibrator 1
- Fluke 715 ma loop calibrators 1
- Fluke 715 volt ma calibrator 1
- Technical data 1
- Fluke keeping your world up and running 2
- Functional specifications fluke 705 and 707 fluke 715 2
- General specifications 2
- Maximum voltage 30 volts non operating temperature 4 c to 60 c operating temperature 10 c to 55 c relative humidity 95 10 c to 30 c 75 30 c to 40 c 45 40 c to 50 c 35 50 c to 55 c operating altitude 3 000 m max shock 1 m drop test vibration random 2 g 5 hz to 500 hz safety csa c22 no 1010 1992 emc en50082 1 1992 and en55022 1994 class b power 9 v battery ansi neda 1604a or iec 6lr619v alkaline two batteries in 718 warranty three years 2
