2 Fluke Corporation Calibration and documentation for process manufacturing: Costs, benefits and feasibility
In so-called “validated” industries (such as
the pharmaceutical industry), any changes to a
process line, including repair or replacement of
a process instrument or a final control element,
must be re-validated and traced to documenta-
tion before the process line can be put back
into service. Poor calibration documentation can
make this validation process time consuming and
expensive and put the manufacturer at risk of
fines by the regulating government agency.
Savings
Calibration and documentation are usually
considered expenses, and the higher efficiency
resulting from good calibration practices may be
hard to distinguish. Consider, then, the known
costs. On the one hand: loss of an entire batch
due to quality issues. On the other: legal costs and
lost revenue from accidents, which at the refinery
mentioned earlier has exceeded $100 million. If
disaster strikes, good calibration records can be
a part of a facility’s defense in the event of legal
action (just as poor records can put an organiza-
tion in a less defensible legal position).
How do field instruments work,
and what kind of calibration do
they require?
Most field instruments are made up of two parts:
a primary element and a transmitter.
• Primary elements include flow tubes, orifice
plates, pressure sensors, wet chemistry sen-
sors such as pH, ORP, and conductivity probes,
level gauges of all types, temperature probes,
and others. Primary elements typically produce
a signal—usually voltage, current, or resis-
tance—that is proportional to the variable they
are designed to measure, such as level, flow,
temperature, pressure, or chemistry. Primary
elements are connected to the input of field
transmitters.
• Field transmitters include pressure, tem-
perature and flow devices. They process the
signal generated by the primary element, first
characterizing it in linear format and applying
engineering unit coefficients to it, before then
transmitting it in analog (usually 4-20mAdc)
or digital format (usually some variety of
fieldbus).
Note: When a field instrument is manufactured, both the
primary element and the transmitter (or the actuator, if a
control valve) are calibrated at the factory and the calibra-
tion information is supplied with the unit. This calibration
data is often lost. Entering this information into centralized
calibration records when the device is put into service
should be part of standard work, and not just for effi-
ciency’s sake. Centralizing calibration information ensures
knowledge stays with the facility even as teams change.
Analog devices
Analog devices—often called “4 to 20 milli-
amp loop” devices—are so called because they
transmit a signal that is an electrical “analog”
representation of a measured physical quantity
(temperature, for example). They transmit an
electric current that is proportional (analogous)
to the magnitude of a measured physical quan-
tity, with 4 milliamps of current representing the
minimum scaled value and 20 milliamps repre-
senting the maximum scaled value. This relatively
simple technology has low sensitivity to electri-
cal “noise” and has been used for many years.
Although many system aspects are now digital,
analog devices are still in active use throughout
the process manufacturing world. A 2010 survey
in Control Global magazine found that 30 % of
plants surveyed continued to use analog instru-
ments and current loops. Because analog circuits
such as current loops drift over time, they require
regular calibration.
Digital devices
Digital devices convert a measured physical value
into a digital signal. Many different digital encod-
ing methods are used in the process industry,
including Foundation, Profibus, and HART.
There is a widespread belief that fieldbus
(digital) field devices do not require calibration.
This is not true.
Although a fieldbus signal (whether Foundation,
Profibus, or connected HART) provides diagnostic
information, it does not provide information about
the accuracy of the device, nor does it verify that
the device is reporting the process accurately
and precisely. For example, a Foundation fieldbus
differential pressure transmitter can report diag-
nostic information about the transmitter, but it
cannot report on the physical condition of the ori-
fice plate across which it is measuring pressure.
Consequently, even if the electronics are operat-
ing perfectly, the flow reading transmitted may be
inaccurate. Thus, calibration is required even for
digital devices.
Fieldbus systems do not have an analog output
that technicians can use to verify the accuracy of
instrument transmissions to the control system.
Without an easily readable output, facilities must
either install a readout display at the device or
perform calibrations with one technician at the
device and the other in the control room. Both
options increase calibration costs.
Control valves
Control valves have actuators that also require
calibration to adjust for wear and the effects of
stiction. Often these valves must be given a partial
stroke test if they haven’t been actuated regularly.
