Fluke 718 ex [2/2] Specifications

Fluke 718 ex [2/2] Specifications
Specifications continued
Environmental and safety requirements
Operating temperature -10 °C to 55 °C
Non-operating temperature -40 °C to 71 °C
Relative humidity 95 % (10 °C to 30 °C)
(%RH operating 75 % (30 °C to 40 °C)
without condensation) 45 % (40 °C to 50 °C)
35 % (50 °C to 55 °C)
Size (LxWxD) 216 mm x 94 mm x 66 mm (8.50 in x 3.72 in x 2.60 in)
Weight 35 oz (992 g)
Vibration Random, 2g, 5-500 Hz
Shock 1 Meter Drop test
EMC EN61326 2002-02, Criteria C
Pressure display (external modules)
Pressure Module Readout
Pressure range Determined by pressure module
Resolution 5 digits
Accuracy Determined by pressure module
Engineering Units (in Hg)
PSI, in. H
2
O (4 °C), in. H
2
O (20 °C), Kpa, cm H
2
O (4 °C),
cm H
2
O (20 °C), BAR, mBAR, Kg/cm2, mmHg, in Hg
Zeroing modes
Mode
Gage and Pushing Zero button stores present pressure value as an offset and subtracts it
differential from the displayed value
Absolute Pushing Zero button causes nominal barometric pressure to be displayed. User corrects
to actual barometric pressure with up/down keys. Difference is used as zero offset calibration.
Current specifications
18 °C to 28 °C, one year
Current Measurement
Range 0 mA to 24 mA
Resolution .001 mA
mA ± 5 °C .02 % Rdg ± 2 count
Temp Coeff.
to 18 °C, ± .005 % of range per °C
to 55 °C
Pressure module specification
(All specifications in % of full span. Specifications reflect a confidence interval of 95 %.)
Range Reference High
2
Low
2
Max over-
Range/ (approx)/ uncertainty Stability Temperature Total
1
side side Fitting pressure
Model Resolution Resolution (23 ± 3 ºC) (1 year) (0 to 50 ºC) uncertainty media media material (x nominal)
Differential
FLUKE-700P01Ex 10 in. H
2
O/0.01 2.5 kPa/0.002 0.200 0.050 0.050 0.300 Dry Dry 316 SS 3x
FLUKE-700P24Ex 15 psi/0.001 103 kPa/0.01 0.025 0.010 0.015 0.050 316 SS Dry 316 SS 3x
Gage
FLUKE-700P05Ex 30 psi/0.001 207 kPa/0.01 0.025 0.010 0.015 0.050 316 SS N/A 316 SS 3x
FLUKE-700P06Ex 100 psi/0.01 690 kPa/0.07 0.025 0.010 0.015 0.050 316 SS N/A 316 SS 3x
FLUKE-700P27Ex 300 psi / 0.01 2070 kPa / 0.1 0.025 0.010 0.015 0.050 316 SS N/A 316 SS 3x
FLUKE-700P09Ex 1500 psi/0.1 10 MPa/0.001 0.025 0.010 0.015 0.050 316 SS N/A 316 SS 2x
Absolute
FLUKE-700PA4Ex 15 psi/0.001 103 kPa/0.01 0.050 0.010 0.010 0.070 316 SS N/A 316 SS 3x
High
FLUKE-700P29Ex 3000 psi/0.1 20.7 M Pa/0.001 0.050 0.010 0.020 0.080 C276 N/A C276 2x
1
Total uncertainty, one year for temperature range 0 °C to +50 °C. Total uncertainty, 1.0 % of full span for temperature range -10 °C to 0 °C.
2
“Dry” indicates dry air or non-corrosive gas as compatible media. “316 SS” indicates media compatible with Type 316 Stainless Steel. “C276”
indicates media compatible with Hastelloy C276.
Operating modes
Mode
Measure pressure (using internal sensor)
Display pressure module reading (automatically selected when pressure module
connected)
Measure current
Input/output
Pressure input 1/8 in. NPT pressure fitting
Pressure module input LEMO connector
Current input Shrouded banana jacks
Battery
Power One 9-volt alkaline battery
Battery life 4 to 20 hours, depending on functions used
Fluke Corporation
PO Box 9090, Everett, WA 98206 U.S.A.
Fluke Europe B.V.
PO Box 1186, 5602 BD
Eindhoven, The Netherlands
For more information call:
In the U.S.A. (800) 443-5853 or
Fax (425) 446-5116
In Europe/M-East/Africa +31 (0) 40 2675 200 or
Fax +31 (0) 40 2675 222
In Canada (800)-36-FLUKE or
Fax (905) 890-6866
From other countries +1 (425) 446-5500 or
Fax +1 (425) 446-5116
Web access: http://www.fluke.com
©2007-2010 Fluke Corporation.
Specifications subject to change without notice.
Printed in U.S.A. 7/2010 2116965F D-EN-N
Modification of this document is not permitted
without written permission from Fluke Corporation.
