Ergolux ELX-SI01-C40 [10/14] Dry ironing

5. Plug the iron in.

6. To avoid clothes damage begin the first time ironing with an old towel.

Warning! On initial use there may be some smoke from the iron due to the lubricant presence.

Dry ironing

1. Place the iron into the vertical position on the ironing board, plug the appliance in.

2. According to the manufacturer’s instructions on the garment label, choose the proper

temperature setting.

3. If you are unsure about the fabric type, test ironing a small area on the garment and choose the

temperature setting.

4. Pilot light will go off to indicate that the required temperature is reached and iron is ready for

operation.

5. Iron delicate fabrics such as silk, wool and synthetic on the inside part of the garment to prevent

shine marks.

6. Iron velvet and glitter fabrics on a soft backing (for example, Turkish towel), in one direction.

7. After use unplug the appliance, pour the water out of the tank and let the iron get cool.

8. Store the iron vertically in the dry place.

1. Do not fill the water tank with water to a dry ironing.

2. Move the steam control knob to OFF (left position, steamless ironing).

3. Select the desired temperature.

4. The light indicator turns off when the iron is ready for operation

Operation instructions

Ironing with steam

1. Fill the water tank with standing or filtered water.

2. Ironing with steam is only possible when choosing the maximum heating temperature of the

soleplate. Otherwise, steam will not form, and water can flow through the soleplate.

3. Plug the steam iron in. Set the maximum temperature. Wait for the light indicator to turn off,

then the selected temperature mode has been reached.

4. Set the steam control to the middle position ON. Adjust the lever the required intensity.

Low t

, min

NYLON

Middle t

WOOL SILK

High t

, max

LINEN COTTON

Symbol Garment

Synthetics, nylon

Wool, silk

Cotton, linen

Do not iron

Temperature
