712B/714B
Calibration Manual
4
RTD Input and Output
RTD Type
(α)
Range (°C)
Measure (°C) Source (°C)
1 Year 2 Year
Source
Current
1 Year 2 Year
10 Ω
Pt(385)
-200 to 100 1.5 3 1 mA 1.5 3
100 to 800 1.8 3.6 1 mA 1.8 3.6
50 Ω
Pt(385)
-200 to 100 0.4 0.7 1 mA 0.4 0.7
100 to 800 0.5 0.8 1 mA 0.5 0.8
100 Ω
Pt(385)
-200 to 100
0.2 °C 0.4 °C
1 mA
0.2
°C
0.4 °C
100 to 800
0.015 %+0.18 °C 0.03 %+0.36 °C 0.015 %+0.18 °C 0.03 %+0.36 °C
200 Ω
Pt(385)
-200 to 100
0.2 °C 0.4 °C
500 μA
0.2 °C 0.4 °C
100 to 630
0.015 %+0.18 °C 0.03 %+0.36 °C 0.015 %+0.18 °C 0.03 %+0.36 °C
500 Ω
Pt(385)
-200 to 100
0.3 °C 0.6 °C
250 μA
0.3 °C 0.6 °C
100 to 630
0.015 %+0.28 °C 0.03 %+0.56 °C 0.015 %+0.28 °C 0.03 %+0.56 °C
1000 Ω
Pt(385)
-200 to 100
0.2 °C 0.4 °C
250 μA
0.2 °C 0.4 °C
100 to 630
0.015 %+0.18 °C 0.03 %+0.36 °C 0.015 %+0.18 °C 0.03 %+0.36 °C
100 Ω
Pt(3916)
-200 to 100
0.2 °C 0.4 °C
1 mA
0.2 °C 0.4 °C
100 to 630
0.015 %+0.18 °C 0.03 %+0.36 °C 0.015 %+0.18 °C 0.03 %+0.36 °C
100 Ω
Pt(3926)
-200 to 100
0.2 °C 0.4 °C
1 mA
0.2 °C 0.4 °C
100 to 630
0.015 %+0.18 °C 0.03 %+0.36 °C 0.015 %+0.18 °C 0.03 %+0.36 °C
10 Ω
Cu(427)
-100 to 260 1.5 3 1 mA 1.5 3
120 Ω
Ni(672)
-80 to 260 0.15 0.3 1 mA 0.15 0.3
50 Ω
Cu(427)
-180 to 200 0.4 0.7 1 mA 0.4 0.7
100 Ω
Cu(427)
-180 to 200 0.2 0.4 1 mA 0.2 0.4
YSI400 15 to 50 0.2 0.4 250 μA 0.2 0.4
100 Ω
Pt(3902)
-200 to 100
0.2 °C 0.4 °C
1 mA
0.2 °C 0.4 °C
100 to 500 0.015 %+0.18 °C
0.03 %+0.36 °C 0.015 %+0.18 °C 0.03 %+0.36 °C
• Notes:
• Sensor inaccuracies not included.
• Resolution: 0.1 °C.
• Read accuracy is based on 4-wire input. For 3-wire RTD measurements, assuming all three RTD leads are
matched, add 1.0 °C (Pt10 and Cu10), 0.6 °C (Pt50 and Cu50), 0.4 °C (Other RTD types) to the specifications.
• Source Accuracy in source mode is based on 0.5 mA~3 mA (1.00 Ω~400.00 Ω), 0.05 mA~0.8 mA
(400.0 Ω~1500.0 Ω), 0.05 mA~0.4 mA (1500.0 Ω ~4000.0 Ω), excitation current (0.25 mA for Pt1000 range).
• Temperature Coefficient: ±0.05 °C /°C (<18 °C or >28 °C) for both measure and source.
• Supports pulsed transmitters and PLCs with pulse times as short as 5 ms.
