TL-WA500G 54M Wireless Access Point User Guide
Figure 4-14 WPA/WPA2
¾ Version - Select one of following versions from the drop-down list:
z Automatic - Select WPA or WPA2 automatically based on the wireless station's
capability and request.
z WPA - Wi-Fi Protected Access.
z WPA2 - WPA version 2.
¾ Encryption -
Select Automatic, TKIP or AES from the drop-down list.
z Automatic - Select TKIP or AES automatically based on the wireless station’s capability
and request.
z TKIP - Temporal Key Integrity Protocol.
z AES - Advanced Encryption Standard.
¾ Radius Server IP - Enter the IP address of the Radius Server.
¾ Radius Port - Enter the port that radius service used.
¾ Radius Password - Enter the password for the Radius Server.
WPA-PSK/ WPA2-PSK
Pre-shared key of WPA, WPA-PSK/WPA2-PSK uses a password or key to authenticate your
wireless connection. The key is an alpha-numeric password between 8 and 63 characters long.
The password can include symbols(!?*_) and spaces. This key must be identical for your wireless
Access Point. Selecting the radio button before WPA-PSK/WPA2-PSK to secure your wireless
network based on pre-shared passphrase.
Figure 4-15 WPA-PSK/WPA2-PSK
¾
Version - Select one of following versions from the drop-down list:
z
Automatic - Select WPA-PSK or WPA2-PSK automatically based on the wireless
station's capability and request.
z
WPA-PSK - Pre-shared key of WPA.
26
