D-Link DWL-G120 [13/39] Using the configuration utility

Select the Wireless Networks tab.

Uncheck the box in the properties window

that enables windows configuration.

D-Link AirPlus G DWL-G120 uses the Configuration Utility as the

management software. The utility provides the user an easy interface to change

any settings related to the wireless adapter. After you have completed the

installation of the DWL-G120 (refer to the Quick Installation Guide that came

with your purchase) whenever you start the computer, the Configuration Utility

starts automatically and the system tray icon is loaded in the toolbar (see

illustration below*.) Clicking on the utility icon will start the Configuration Utility.

Another way to start the Configuration Utility is to click on Start >Programs

>D-Link AirPlus G >D-Link AirPlus G Utility.

Using the Configuration Utility

If you are using Windows XP, you can use either the Zero Configuration Utility

or the D-Link Configuration Utility.

If the icon does not display in the taskbar, then click on

this icon on your desktop to open.

To use the D-Link Configuration Utility with XP, right-click

on the Wireless network icon in the taskbar in the lower

right-hand corner of your computer screen.

In the window that appears, select

View Available Wireless Networks

and click the Advanced button. The

screen at right will appear.

After you have done this, you can then use the D-Link

Configuration Utility with XP by clicking on the D-Link

Configuration Utility icon.

*Configuration Utility icon

in the system tray
