Position Amount Type number Description PG

1 1 344494270 Cable with plug 21

2 1 344101140 Cable sleeve 13

3 2 141123450 Fillister head screw 11

4 1 343392970 Cable clip 11

5 1 343050140 Terminal rail 12

6 1 311010580 Field coil assembly w.field coil,230V 21

7 1 344496860 Strand set condensor 13

8 1 343408380 Switch 14

9 1 343392680 Housing w.cover 27

10 1 338120540 Metabo label,FSX 200 Intec 11

11 1 316040720 Dust collector cartridge compl. 19

12 1 344097650 Brake ring 12

13 1 339006950 Guide plate 11

14 1 141112180 Countersunk screw 11

15 1 343392810 Intermediate flange 11

16 1 339160720 Backing pad 27

17 4 141151860 Washer 11

18 4 141150350 Lock washer 11

19 1 141113040 Fillister head screw 11

20 4 141123430 Fillister head screw 11

22 1 338051480 Rating plate 11

23 2 344097680 Rubber plug 14

24 1 316040700 Brush holder complete 11

25 1 316040690 Carbon brush set 18

26 1 143115170 Ball bearing,6x19x6 16

27 1 141156290 Washer 11

28 1 344097640 Switch guard 11

29 1 310008990 Armature cpl. 230 V 27

30 2 141151070 Washer 12

31 1 143114990 Ball bearing, 9x26x8 24

32 1 330001760 Fan 22

33 1 315202350 Bearing flange 15

34 1 141156310 Washer 11

35 1 143110220 BALL BEARING, 15x32x9 26

36 1 343392800 Baffle 11

1001 1 338504500 Wiring diagram
