MFE 30

Position Amount Type number Description PG

1 5 141116020 Self-tap fill h screw 12

2 1 341513790 Bolt 15

3 1 339006520 Sealing washer 11

4 1 343373720 Push button black 11

5 1 342001550 Pressure spring 11

6 1 316029310 Gear housing cpl. 34

7 1 341100940 Hexagon nut w.recess 12

8 1 316030170 Bevel gear 29

9 1 339006390 Washer,7,05x19,5x0,2 11

10 1 143115060 Ball bearing, 8X 22X 7 18

11 1 343373670 Cover 13

12 1 316031210 Fan w. prot. Grid 21

13 1 310007810 Armature 230 V Electronic 45

14 1 143114900 Ball bearing, 6X 19X 6 18

15 1 344095260 Rubber bushing 12

16 1 339150890 Baffle 12

17 1 311009890 Field coil 230 V El 36

18 1 338041650 Rating lable 11

19 1 343394180 Switch slide 11

20 1 343391880 Switch rod 11

22 1 343362490 Cable clip 12

23 3 141116990 Self-tap. fill. h. screw 12

24 1 343376710 Housing with cover 16

25 1 316029480 Friction washer cpl. 22

26 1 141152300 Washer 10,2 X 14,8X 0,1 12

27 1 141155560 Washer 11

28 1 341051480 Intermediate piece 13

29 1 343373420 Flange complete 25

30 1 343375540 Sealing washer 11

31 4 141119860 Fillister head screw 12

32 1 341161030 Spindle shaft 27

33 1 316030160 Safety clutch 39

34 2 339060160 Compensating Washer 12

35 1 341031160 Clamping flange 22

36 4 341012140 Spacer ring 14

37 1 341101650 Clamping nut M14 23

38 3 141113890 Cap screw 12

39 1 315415570 Holder 34

40 1 314000540 Handle cpl. 22

41 1 315415410 Extraction hood 41

42 2 141112160 Countersunk screw 12

2/5
