Metabo BS 14.4 LT 602100500 [2/3] Bs 14 lt

BS 14.4 LT

Position Amount Type number Description PG

2 7 141113180 Self-tap. fill. h. screw 11

4 1 316049970 Gear-box compl. 32

6 2 141122220 Fillister head screw 12

8 1 317004150 Motor, 14,4 V (LT) 45

9 1 316050450 Switch slide compl. 12

10 1 343431110 Housing w.cover 26

11 1 342021670 Spring clip 11

12 1 343430890 Switch slide,R/L 11

14 1 343397990 Pressure plate 11

15 1 343394790 Switch slide 11

16 1 343409740 Electronic switch,DC 14,4V 38

17 1 338058330 Rating plate 11

25 1 143160080 Toroidal Ferrite OD11.5*ID5*9 13

26 1 343083380 LED lense 13

27 1 339137270 Hook 13

30 1 316052130 Bit holding sleeves right 13

1001 1 338504870 Wiring diagram

2/3
