! The appliance must be installed by a qualied person

in compliance with the instructions provided.

Wear gloves when carrying out installation and

maintenance operations.

AIR VENT

(for ducting versions)

! Prepare the hole and the air vent duct (150 mm

diameter).

! Use a duct of the minimum indispensible length.

! Use a duct with as few elbows as possible (maximum

elbow angle: 90°).

! Avoid drastic changes in the duct cross-section.

! Use a duct with an as smooth as possible inside.

! The duct must be made of certied material.

! Do not connect the hood to smoke exhaust ducts

for the products of combustion (boilers, replaces,

stoves, etc).

! For the air vents comply with the provisions laid down

by the competent authorities.

In addition, the air must not be evacuated through a

hole in the wall unless specically intended for this

purpose.

! Fit air intakes in the room to prevent the hood from

creating a negative pressure in the room (which must

not exceed 0.04 mbar); if the hood is used at the

same time as non-electrical equipment (gas-, oil- and

charcoal-red stoves, etc.) the exhaust gas may be

sucked in by the heat source.

FILTERING OR DUCTING VERSION ?

The hood may be in ltering or in ducting version.

Decide from the outset which type is to be installed.

For better efciency, we recommend installing the hood

in the ducting version (if possible).

Ducting version

The hood puries the air and evacuates it to the outside

through an exhaust duct (diameter 150 mm).

Filtering version

The hood puries the air and recycles the clean air

back into the room.

CONTROLS

Speed display

PU5: ON/OFF Motor 4

speed

PU4: ON/OFF Motor 3

speed

PU3: ON/OFF Motor 2

speed

PU2: ON/OFF Motor 1

speed

PU1: ON/OFF Lights

5’ timer function:

Pressing PU2, PU3 or PU4 for two seconds when the

motor is set to the corresponding speed, the 5’ timer

function is activated.

The corresponding LED starts blinking to display this

function.

After ve minutes of operation the motor is turned off.

If you change the speed while the timer is running, the

function is NOT deactivated. To deactivate the function,

press the blinking key for two seconds.

NOTE – the 5’ timer function can be activated for

the normal speeds only (1st, 2nd, 3rd)

Buzzer:

Each time the key is pressed, a beep is sounded.

Filter alarm:

After 30 hours of motor operation, the grease lter

alarm is activated (all the LEDs come on). The alarm is

activated when the motor is off and remains displayed

for 30”. To deactivate the alarm, press one of the keys

for 2” during alarm display. After 120 hours of motor

operation, the charcoal lter alarm is activated (all the

LEDs blink). The alarm is activated when the motor is

off and remains displayed for 30”. To deactivate the

alarm, press one of the keys for 2” during alarm display.
