Pyramida WH 60 Белая [31/48] Recirculation mode

Do not forget to include the hood as soon as you start to use

the oven or hob. It is necessary for proper ventilation kitchen.

For a complete ventilation, turn off ventilation hood is not

earlier than 15 minutes after the cooking process.

Hood is equipped with front panel control, which is a series

of buttons. By buttons «•», «• •», «• • •» the gear shifting.

When heating food enough work hood on low speed. For

standard conditions of preparation (cooking and frying for

1-2 burners) used average speed.

High speed is intended to remove from the premises of

a large amount of steam, and the mixed smell of cooking,

working simultaneously all the burners.

Switching speed buttons can be performed in any order.

To turn off the fan, use the button «0».

contRol PAnel

ReciRcUlAtion mode

When working in recycle mode exhaust clean air back into

the kitchen.

To switch from ventilation to recirculation mode to air:

- Redirect the air flow inside the hood of the duct to the

shutters on the upper surface of the hood.

Switching the direction of airflow implemented effected

by the switching regulator of damper on the fan housing.

To access the regulator must remove the fat filters.

- Install a carbon filter in hood. Carbon filter is not supplied

and sold separately.

Carbon filters can not be cleaned and replaced with new

every 3-4 months.

In hood Pyramida WH 10-50, WH 20-60, GH 20-60 slim

sets a carbon filter. In the hood Pyramida WH 22-60 – two

filters.

1. To turn on or turn off the

backlight.

2. To turn off the fan.

3. To turn on low speed of the

fan

4. To turn on average speed of

the fan

5. To turn on high speed of the

fan

Regime of ventilation

Regime of recirculation

1 2 43 5
