19
Using the Configuration Menu (continued)
Advanced > Grouping
Load Balance: Select Enabled or Disabled.
Link Integrity: Select Enabled or Disabled
User Limit: Set the User Limit in this field (0-64)
When you Enable Load Balance you allow several DWL-7000APs to balance
wireless network traffic and wireless clients among the DWL-7000APs with the
same group name. After selecting this option, you will be prompted to enter a
Group Name. All the APs that share Load Balancing must have the same Group
Name and the same SSID. Assign each Access Point a different non-overlapping
channel (e.g., 1, 6, 11).
Ethernet Link Status: This field displays the Ethernet Link Status. Link Up indicates
that there is an Ethernet LAN connection to the AP.
When Link Integrity is Enabled, whenever the Ethernet connection
between the LAN and the AP is disconnected - then the Wireless
segment associated with the AP will also be disconnected from the AP.
