LED Display
Front Panel
LED Display
On Blink Off
Power
Unit is plugged in and
working normally.
Unit is booting up and
running self diagnostic
test
Unit is not plugged in
and it is off
LAN
Ethernet cable is
plugged in and there
is a valid network
connection.
The Ethernet port is
active
Ethernet cable not
plugged in or the
connection is not valid
WLAN
N/A
Detecting Wireless
LAN network activities
No Wireless LAN
network available in
the vicinity
