ViewSonic VOT132 14
Onboard Device Configuration
Onboard Device Configuration Onboard LAN Controller
Onboard LAN Controller [Enabled]
Onboard LAN ROM [Disabled]
Audio Controller [Enabled]
← Select Screen
↑↓ Select Item
+/- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C) Copyright 1985-2006, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
►OnboardLANController[Enabled]
This item is used to enable or disable the Onboard LAN Controller.
►OnboardLANROM[Disabled]
This item is used to enable or disable the Onboard LAN ROM.
►AudioController[Enabled]
This item is used to enable or disable the Audio Controller.
Chipset Menu
Advanced Chipset Settings iGPU Frame Buffer Size Auto
Detect
iGPU Frame Buffer Detect [Disabled]
iGPU Frame Buffer Size [256MB]
← Select Screen
↑↓ Select Item
+/- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 (C) Copyright 1985-2006, American Megatrends, Inc.
Main Advanced Security Boot Security Exit
BIOS SETUP UTILITY
Chipset
►iGPUFrameBufferDetect[Disabled]
This item is used to enable or disable iGPU Frame Buffer Size auto detcet.
►iGPUFrameBufferSize[256MB]
This item is used to select iGPU Frame Buffer Size.Setting options:32MB,64MB,128MB,
256MB,512MB.
