Philips HX6762/43 [13/44] Cord wrap facility specific types only

When you use the Clean and White mode, you hear and feel a

change in the brush head sound and motion after 2 minutes of

Clean mode. Then move the brush head to the visible upper

front teeth and brush them for 15 seconds. At the final beep and

pause, move to the visible lower front teeth and brush them for

15 seconds. (Fig. 9)

Cord wrap facility (specific types only)

If your Sonicare type includes the deluxe charger cover and base, the

travel charger is pre-installed inside the cover. If you want to shorten

the mains cord, you can store excess cord in the cord wrap facility in

the charger base.

1 To separate the charger cover from the charger base, press the

two grey snap bars on the charger base and pull the white charger

cover upwards. (Fig. 10)

2 Wrap excess mains cord around the grey charger base as shown in

the picture. Make sure you wrap the cord on the inside of the two

snap levers. (Fig. 11)

3 When you have stored the excess cord, guide the mains cord

through the small groove in the rear of the grey charger base. (Fig.

12)

4 To reattach the charger cover, press it down over the charger base

until it snaps into place.

Tip: For extra convenience during travel, you can remove the travel

charger and use it without the charger cover and charger base.

Cleaning

Do not clean brush heads, the handle, the charger or the charger

covers in the dishwasher.

Toothbrush handle

1 Remove the brush head and rinse the metal shaft area with warm

water. Make sure you remove any residual toothpaste (Fig. 13).

Caution: Do not push on the rubber seal on the metal shaft with

sharp objects, as this may cause damage.

2 Wipe the entire surface of the handle with a damp cloth.

English
