BIOS Setup - 44 -
(Note) This item appears only if you install a CPU that supports this feature.
2-5 Advanced BIOS Features
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Advanced BIOS Features
IGXConguration [PressEnter]
AMD C1E Support
(Note)
[Disabled]
Virtualization [Disabled]
Patch AMD TLB Erratum
(Note)
[Enabled]
AMD K8 Cool&Quiet control [Auto]
Hard Disk Boot Priority [Press Enter]
First Boot Device [Hard Disk]
Second Boot Device [CDROM]
Third Boot Device [Floppy]
Password Check [Setup]
HDD S.M.A.R.T. Capability [Disabled]
Away Mode [Disabled]
Backup BIOS Image to HDD [Disabled]
Init Display First [PCI Slot]
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
IGX Conguration
The settings in this submenu are synchronous to those under the same items on the MB Intelligent
Tweaker(M.I.T.) main menu.
AMD C1E Support
(Note)
Enables or disables the C1E CPU power-saving function in system halt state. When enabled, the CPU
core frequency and voltage will be reduced during system halt state to decrease power consumption.
(Default: Disabled)
Virtualization
Virtualization allows a platform to run multiple operating systems and applications in independent parti-
tions. With virtualization, one computer system can function as multiple virtual systems.
(Default: Disabled)
Patch AMD TLB Erratum
(Note)
Enables or disables the Patch AMD TLB Erratum function. (Default: Enabled)
AMD K8 Cool&Quiet control
Auto Lets the AMD Cool'n'Quiet driver dynamically adjust the CPU clock and VID to
reduce heat output from your computer and its power consumption. (Default)
Disabled Disables this function.
Hard Disk Boot Priority
Speciesthesequenceofloadingtheoperatingsystemfromtheinstalledharddrives.Usetheupor
down arrow key to select a hard drive, then press the plus key <+> (or <PageUp>) or the minus key <-> (or
<PageDown>)tomoveitupordownonthelist.Press<Esc>toexitthismenuwhennished.
