Hardware Installation - 10 -
1-2 Product Specications
CPU
Support for AM3 processors:
AMD Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport Bus
5200 MT/s
Chipset
North Bridge: AMD 760G
South Bridge: AMD SB710
Memory
2 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory
(Note 1)
Dual channel memory architecture
Support for DDR3 1333(O.C.)/1066/800 MHz memory modules
Support for non-ECC memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory modules.)
Onboard Graphics
Integrated in the North Bridge:
- 1 x D-Sub port
- 1 x DVI-D port
(Note 2) (Note 3)
- 1 x HDMI port
j
(Note 3)
Audio
Realtek ALC888B codec
HighDenitionAudio
2/4/5.1/7.1-channel
(Note 4)
Support for S/PDIF Out
Support for S/PDIF In
Support for CD In
LAN
1 x Realtek RTL 8111D/E chip (10/100/1000 Mbit)
Expansion Slots
1 x PCI Express x16 slot, running at x16
(The PCI Express x16 slot conforms to PCI Express 2.0 standard.)
1 x PCI Express x1 slot
2 x PCI slots
Storage Interface
South Bridge:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 10, and JBOD
iTE IT8718 chip:
- 1xoppydiskdriveconnectorsupportingupto1oppydiskdrive
USB
South Bridge
:
- Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
j
Only for GA-MA78LMT-S2H
