GA-MA770T-UD3/US3 Motherboard - 60 -

3-6 Download Center

To update the BIOS, drivers, or applications, click the Download Center button to link to the GIGABYTE

Web site. The latest version of the BIOS, drivers, or applications will be displayed.
