5. INSTALLATION
1. Connect loading to output AVR NEO R.
2. Connect the AVR to a power line 220 V.
3. Switch on the AVR.
The indicator in the switch will be lit.
The indicator «Stabilization» will quickly be lit.
During self-testing indicators «Overload» and «Line» will be shone.
4. After 10 second self-testing, indicator «Overload» will go out and indicator «Line» will be lit and a voltage will be
connected to target sockets.
If indicator «Overload» after testing will not go out to maintain the stabilizer it is forbidden.
5. At job of the AVR boost or buck of an entrance voltage indicator «Stabilization» will be shone.
6. In case of an overload or short circuit the AVR will disconnect of a voltage. After elimination of the reason of an
overload the stabilizer is necessary for switching on again.
7. At a voltage on an input from above 280 volt the AVR will be disconnected. Thus indicator «Overload» will be shone.
6. TROUBLESHOOTING
Situation Check Items Solution
The AVR does not work. 1. Is the power switch on?
2. Is the voltage in the entrance
socket?
3. Too powerful loading is connected.
1. Press Main Switch on.
2. Be convinced available an
entrance voltage.
3. Disconnect a part of loading.
The indicator «overload» does not
die away and there is no target
voltage.
1. Failure of the scheme of testing.
2. The AVR is faulty.
3. An entrance voltage too high.
Switch-off and anew switch on
the AVR.
If the problem is not eliminated
it is necessary to address in the
service center.
The AVR often clicks, thus indicator
«Stabilizer» lights up.
The entrance voltage is very instability. It is normal. The AVR adjusts a
target voltage.
The AVR has disconnected loading.
The indicator «Overload» is shone.
An entrance voltage too high. When the input voltage becomes
normal the AVR will work.
7. SPECIFICATIONS
Specification/model NEO R 600 NEO R 1000
Maximum load 600 VА/300 W 1000 VА/500 W
Protection Over current, short circuit, overload, against a lightning
Surge energy rating 320 J
Indicators LEDs indicating Output off, Normal, AVR
Input EURO socket
Output 2 pc EURO socket 2 pc EURO socket + IEC 320
Operating environment 0–40 °C, 10–90 % RH, non condensing
Agency Approval CE, RusTest
Input Voltage Range 150–280 V
Output Voltage Range 195–248 V
Frequency 50/60 Hz
Dimension, mm 118 х 112 х 106 124 х 124 х 119
Weight, kg 1.64 2.12
Notes:
1). The specifications listed above are f or reference only.
2). The technical specifications of this device are subject to changes without prior notice.
Durability — 5 years.
Eng NEO R 600/1000
7
