Sven Pl 1.8m gr [2/2] Platinum pro

platinum PRO

ENG

Thank you for buying filters SVEN!

Filters are produced specially for connecting electrical devices to power supply and for protecting them from highvolt

age spikes and highfrequency interference.

SVEN PLATINUM PRO FILTER’S FEATURES

Power supply pointer indicator

Protection circuit LED indicator

Six universal sockets with ground contact

Six switches for independent socket commutation

Improved RFI/EMI noise filter

Automatic Recoverable Circuit Breaker

Local network and modem protection

Wall attaching

PRECAUTIONS

Do not connect filter to power 380 V

Do not allow the device contact with thinners

Do not put the device in damp circumstances, prevent from moisture, dust and high temperatures

Do not connect simultaneously devices with total power more then 2,2 kW

Do not open and repair the device independently

CONNECTION

1. Connect all the necessary equipment to the filter sockets.

3. Connect filter to power supply 220 V. To LED`s switch on the front panel, pointing that protection circuit works and there

is supply voltage.

4. Switch on the tumbler opposite the socket which is necessary to connect.

Indicator in tumbler switches at the connection.

SPECIFICATIONS

Note. Given specification may not serve the bases for claims.

Power rating, V 220

Load power rating, kW 2,2

Working frequency, Hz 50

Thermal circuit breaker recoverable, 10 А

Surge protector phaseneutral

phaseground

neutralground

RFI/EMI noise filter 60–1000

Maximum energy dissipation, J 3 х 200

Maximum spike current, А 5000

Output sockets (EURO)

Sockets for phone and modem protection

RJ11/45

Package size, mm 255 х 105 х 40

OPERATION MANUAL
