Philips 170X4FS [11/84] Optical characteristics

• Input Frequency

SXGA Hsync 64-81 kHz, Vsync 60-76 Hz (N.I.)

XGA Hsync 48- 61 kHz, Vsync 60 - 76 Hz (N.I.)

SVGA Hsync 35- 50 kHz, Vsync 56 - 75 Hz (N.I.)

VGA Hsync 31- 38 kHz, Vsync 60 - 76 Hz (N.I.)

AUDIO

• Input signal level 0.5 V RMS

• Input signal connector 3.5mm mini jack

• Brightness

260 cd/m

2

(typ.)

• Peak contrast angle 6 o'clock

• White Chromaticity

x: 0.283 y: 0.297 (at 9300° K)

x: 0.313 y: 0.329 (at 6500° K)

x: 0.313 y: 0.329 (at sRGB)

• Viewing Angle (C/R >5)

Upper >80° (typ.)

cameras, monitors, printers, scanners, etc.)

Using a standard unified color space, sRGB will help represent pictures taken by an sRGB compatible

device correctly on your sRGB enabled Philips monitors. In that way, the colors are calibrated and you

can rely on the correctness of the colors shown on your screen.

Important with the use of sRGB is that the brightness and contrast of your monitor is fixed to a

predefined setting as well as the color gamut. Therefore it is important to select the sRGB setting in the

monitor's OSD.

To do so, open the OSD by pressing the OK button on the front of your monitor. Use the down button

to go to Adjust Color and press OK again. Then move the down button to go to sRGB and press OK

again.
