Technical Specifications
DFL-100
Hardware
WAN
Firewall
Router
Device Ports
- 1 10/100Mbps Fast Ethernet port for DSL/cable modem connection
- 1 10/100Mbps Fast Ethernet DMZ port
- 3 10/100Mbps Fast Ethernet switch ports (for internal LAN connection)
DMZ & LAN Port Support
- Full/half duplex
- Auto MDI/MDIX
- 802.3x Flow Control in full duplex
- Back pressure in half duplex
Memory
- Boot ROM & runtime code: 2MB flash
- Buffer: 32MB SDRAM
PPPoE
- Method for Transmitting PPP over Ethernet (RFC 2516)
- Point-to-Point Protocol (PPP) (RFC 1661)
- PPP Internet Protocol Control Protocol (IPCP) (RFC 1332)
- PPP Authentication Protocol (RFC 1334)
- PPP Encryption Control Protocol (ECP) (RFC 1968)
- PPP Compression Control Protocol (CCP) (RFC 1962)
- PPP Challenge Handshake Authentication Protocol (CHAP) (RFC 1994)
- Microsoft PPP CHAP Extensions I and II (RFC 2433, 2759)
- Microsoft Point-To-Point Encryption (MPPE) Protocol (RFC 3078)
- Various Encryption Protocols
Stateful Packet Inspection
- IP Address and Port Number
- Packet Count and Byte Count
- Sequence and Acknowledgement Number
- Timestamps
- Payload Modification History
- Dynamic Association
Logging
- Filtering activities: rejected internal and external connection request
logging
- Session tracking activities: session creation and termination information
logging
- Intrusion detection activities: outside attack logging
- User authentication activities: user authenticating with firewall logging
DoS Blocked Attack Types
- SYN Flooding
- TCP Hijacking
- LAND Attack
- WinNuke / OOBNuke
- Christmas Tree
- SYN/FIN (Jackal)
- SYN/FIN (zero-sized DNS zone payload)
- BackOffice (UDP 31337)
- NetBus
- Smurf
- Tear Drop
- ICMP Flooding
- Trojan Horse
NAT
- IP Network Address Translation (NAT) (RFC 2663)
- Traditional IP Network Translation (Traditional NAT) (RFC 3022)
- Protocol Complications with IP Network Address Translation
(RFC 3027)
NAT Application Level Gateway
- H.323 Protocol Suite
- File Transfer Protocol (FTP)
- Session Description Protocol (SDP)
- Real-Time Transport Protocol (RTP)
- Internet Relay Chat (IRC)
- Multiple Gaming Protocol
Firewall/VPN Router
Network & Routing Protocols
- TCP/IP, UDP, ARP, ICMP, TFTP, Telnet, SNMP, HTTP
- Routing Protocol: Static and Default Routing
Server
- DHCP server for automatic IP assignment
- Virtual server mapping (maximum: 32)
PPTP
- Point-to-Point Tunneling Protocol (RFC 2637)
- Layer Two Tunneling Protocol (RFC 2661)
Connection Modes
- Site to site
- Site to client
Number of Tunnels
IPSec tunnels (maximum: 80)
IPSec
- Security Architecture for the Internet Protocol (RFC 2401)
- IP Security Document Roadmap (RFC 2411)
- IP Authentication Header (RFC 2402)
- IP Encapsulating Security Payload (RFC2406)
- IP Payload Compression Protocol (RFC 2393)
- Internet IP Security Domain of Interpretation for ISAKMP (RFC 2407)
- HMAC: Keyed-Hashing for Message Authentication (RFC 2104)
- Use of HMAC-MD5-96 within ESP and AH (RFC 2403)
- Use of HMAC-SHA-1-96 within ESP and AH (RFC 2404)
- All AH and ESP Transforms
Encryption Algorithms
- DES & 3DES (with hardware accelerator aid)
- RC4
UDP Encapsulation
- Allows firewalls and NAT gateway to handle IPSec traffic
- Follows IPSec standards for UDP encapsulation
Advanced Key Management
- Internet Security Association and Key Management Protocol (ISAKMP)
(RFC2408)
- Internet Key Exchange (IKE) (RFC 2409)
Supported IKE Mechanisms
- Pre-shared Key
- Default 768 bits MODP Group
- Default 1024 bits MODP Group
Diagnostic LEDs
- Link/Act (per port)
- 100Mbps (per port)
- Power (per device)
Power Input
- DC 5V 2.5A
- Through external AC power adapter
Dimensions
234 (W) x 161 (D) x 35 (H) mm
Weight
360 grams (approx.)
Operating Temperature
-5 C ~ 50 C
Storage Temperature
-25 55 C
Operating Humidity
10% - 95% non-condensing
VPN & Data Encryption
Physical & Environmental
