Hyundai H-TV1403 [4/46] Preparation

Colour TV features

· 14 (37 cm)

· PAL/SECAM BG/DK receiving and playback

· NTSC 3,58 & 4,43 playback only

· 2 front speakers

· Stereo, maximum output power 2x1.5 W

· 255 program memory

· Auto & manual programmable scan

· 4 preset image modes

· Multifunctional colored Russian / English OSD

· Multifunctional Remote Control

· Child lock function

· Clock

· Off programmable timer

· Real time On/Off programmable timer

· Side and back Audio / Video input jack

· Headphone jack

· Adjustment resume function

Preparation

Connection of antenna

Indoor antenna

Connect the end of feeder from the telescopic antenna to a 75 Ohm ~ 300 Ohm converter and plug the converter into the antenna socket on the rear of

the unit. Adjust the antenna length, angle and direction until optimum reception is achieved.

Outdoor antenna

When the optimum reception cannot be obtained with indoor antenna due to shielding by concrete building, nearby tall buildings or hills, outdoor

antenna is required for better reception.

When 75 Ohm coaxial cable is used for wiring, directly plug antenna into the antenna socket on the rear of the unit.

When 300 Ohm flat feeder cable is used for wiring, trim the end of feeder cable as the following figure shown, and connect the end to a 75 Ohm ~ 300

Ohm converter, then plug the converter into the antenna socket on the rear of the unit.
