5. SPECIFICATIONS

LPF - 2000-2500 Hz (12 dB/Oct)

DB-P128NEO: HPF - 80-100 Hz (24 dB/Oct)

Frequency responce

Magnet type

Mounting depth

Mounting diameter

Power RMS

Size

Series

Impedance

Type

Basket type

SPL (1 W / 1 m)

60-3500 Hz

Neodymium

134,5 mm

282 mm

200 Watt

12"

Deaf Bonce

8 Ohm

Mid-Bass

Moulded

96 dB

Voice coil diameter 3"

Fs 62 Hz

Model DB-P128NEO

Vas 46.16 L

BL 15.98

Qts 0.41

The correct choice of amplifier settings, filtering and enclosure largely influence on the lifespan of your audio system. You should select an

amplifier with a nominal power, not exceeding the nominal power of the speakers. Proper coordination of the head unit (HU) of the amplifier

will allow to get a clean, undistorted signal applied to the component to prevent overheating and voice coil damage. The recommended HU

volume is not more than 80%, input sensitivity of the amplifier is 50%.

The recommended filter settings:

The high pass filter HPF (a Filter that cuts off all frequencies below the frequency setting of the filter) is about 80-100 Hz (24

dB/Oct), or 100-110 Hz (12 dB/Oct)

The low pass filter LPF (a Filter that cuts off all frequencies above the frequency of the filter) - 2000-2500 kHz (12 dB/Oct).

Recommended amplifiers: AE-150.4, HLX-4.180, HLX-2.300, DB-OGO2500D, M134, M84, M54, DB-OGO1500.2D, MFC-

120.2, MFC-90.4.

4. FILTERING, RECOMMENDED AMP L I F I E R S E T T I N G S .
