2.1 Installation
221E2/221EL2
Package contents
2. Setting up the monitor
Note
Use only the AC/DC adapter model ADPC1236/
FSP036-DGAA1/LCAP07F-2
Install base stand
221E2/221EL2
1. Place the monitor face down a smooth
surface taking care to avoid scratching or
damaging the screen.
2. Attach the monitor base stand to the base
column then fasten base stand.
Connecting to your PC
DC power input
VGA input
DVI-D input(Available for selected models)
Kensingtonanti-thieflock
Connect to PC
1. Connect the power cord to the back of
the monitor firmly.
2. Turn off your computer and unplug its
power cable.
3. Connect the monitor signal cable to the
video connector on the back of your
computer.
4. Plug the power cord of your computer
and your monitor into a nearby outlet.
5. Turn on your computer and monitor.
If the monitor displays an image,
installation is complete.
