xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Switch Hardware Installation Guide
4
Ports
DGS-3120-24TC
Twenty Copper ports (10/100/1000Mbps).
Four Combo Copper/SFP ports (10/100/1000Mbps and 100/1000Mbps).
Two dedicated, high speed stacking ports.
DGS-3120-24SC
Sixteen SFP ports (100/1000Mbps).
Eight Combo Copper/SFP ports (10/100/1000Mbps and 100/1000Mbps).
Two dedicated, high speed stacking ports.
DGS-3120-24SC-DC
Sixteen SFP ports (100/1000Mbps).
Eight Combo Copper/SFP ports (10/100/1000Mbps and 100/1000Mbps).
Two dedicated, high speed stacking ports.
DGS-3120-24PC
Twenty Copper PoE ports (10/100/1000Mbps).
Four Combo Copper PoE/SFP ports (10/100/1000Mbps and 100/1000Mbps).
Two dedicated, high speed stacking ports.
DGS-3120-48TC
Fourty-four Copper ports (10/100/1000Mbps).
Four Combo Copper/SFP ports (10/100/1000Mbps and 100/1000Mbps).
Two dedicated, high speed stacking ports.
DGS-3120-48PC
Fourty-four Copper PoE ports (10/100/1000Mbps).
Four Combo Copper PoE/SFP ports (10/100/1000Mbps and 100/1000Mbps).
Two dedicated, high speed stacking ports.
• All the switches are equipt with one RJ-45 Console port (a special console cable with a DB9 interface is provided
to connect the Switch to a PC)
• All the switches, except for the DGS-3120-24SC-DC, are equipt with one Redundant Power Supply (RPS) outlet
for optional external RPS
NOTE: For customers interested in D-View, D-Link Corporation's proprietary SNMP management
software, go to http://dview.dlink.com.tw/
and download the software and manual.
