xStack
®
DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch Hardware Installation Guide
42
Stacking ID
Green Capable 1 – 12, H,
h, G
The box ID is assigned either by user
(static mode) or by the system
(automatic mode). When the box
become a primary master, the 7
segment works as bi-function. That is
box ID and “H” indicate as primary
Master and the display will be shown
by turn. That is boxID -> H -> boxID -
> H
1-12: To indicate the stacking of the
switch
H: When device was assigned as the
stacking Master
h: When device was selected to be
the Backup Master
G: When Safeguard Engine entering
the exhausted mode.
Port LED Mode
Indicator
A LED Mode Select Button to switch two modes in turn for all
10/100/1000Mbps ports on DGS-3620-28PC/52P:
• Link/Act/Speed Mode
• PoE Mode
Green Solid Light A LED Mode Select Button to switch
Link/Act/Speed Mode
Solid Light A LED Mode Select Button to switch
PoE Mode
LED Per
10/100/1000 Mbps
Port
Link/Act/Speed
Mode
Green Solid Light
W
hen there is a secure connection (or
link) to 1000Mbps Ethernet device at
any of the ports.
Blinking When there is reception or
transmission of data occurring at
1000Mbps.
Orange Solid Light W
hen there is a secure connection (or
link) to 10/100Mbps Ethernet device
at any of the ports.
Blinking When there is reception or
transmission of data occurring at
10/100Mbps.
Off Light off No link.
PoE Mode
Green Solid Light Power feeding.
Orange Solid Light Error Condition.
Off Light Off No Power feeding.
LED per SFP Port
Link/Act
Green Solid Light
When there is a se
cure connection (or
link) to 1000Mbps Ethernet device at
any of the ports.
Blinking When there is reception or
transmission of data occurring at
1000Mbps.
Orange Solid Light W
hen there is a secure connection (or
link) to 100Mbps Ethernet device at
any of the ports.
Blinking When there is reception or
transmission of data occurring at
100Mbps.
