D-Link DMC-805X [4/16] Installation
![D-Link DMC-805X [4/16] Installation](/views2/1460099/page4/bg4.png)
4
Product Features
Compliance with IEEE802.3ak CX4 XAUI and
IEEE802.3ae/aq 10GBASE SFP+
One-channel media conversion between
10GBASE-CX4 and 10GBASE-SR/ER/LR/LRM/ZR
SFP+ module
Extends network connection to various lengths
depending on SFP+ transceiver capability
Used as stand-alone converter or installed in D-Link
special designed chassis (DMC-1000)
Provides intelligent functions such as LLR (Link Loss
Return) and LLCF (Link Loss Carry Forward)
Front panel status LEDs
Hot-swappable when installed in a standard
rack-mount chassis (DMC-1000)
Installation
This chapter gives step-by-step installation instructions
for the DMC-805X.
Selecting a Site for the Equipment
As with any electric device, you should place the
equipment where it will not be subjected to extreme
temperatures, humidity, or electromagnetic interference.
Specifically, the site you select should meet the following
requirements:
