Kavo MASTERmatic M29 L [22/76] Technical specifications m20 l
![Kavo MASTERmatic M29 L [22/76] Technical specifications m20 l](/views2/1461268/page22/bg16.png)
The shank can be mounted on all INTRAmatic motors and motors fitted
with a connection in accordance with ISO 3964 / DIN 13940.
3.3 Technical Specifications M20 L
Drive speed max. 40,000 rpm
Step-down ratio 1 : 1
Maximum speed: max. 40,000 rpm
Identification 1 blue ring
Spray water pressure 0.8 to 2.0 bar (12 to 29 psi)
Spray air pressure 1.0 to 2.0 bar (15 to 29 psi)
Spray air quantity min. 1.5 Nl/min (at 2 bar)
Cooling air flow 5.5 to 9.5 Nl/min
All INTRA heads and INTRA LUX heads can be used.
3 Product description 22 / 74
