JVC DLA-VS2500ZG [10/56] Accessories optional accessories

Accessories/Optional Accessories

Check the Accessories

Power cord (for USA) (about. 2 m) ......................................... 1 piece

Power cord (for EU) (about. 2 m) ............................................ 1 piece

Optional Accessories

Remote control: Model no. RM-MH13G

AAA-size battery

Getting Started
