Hyundai H-LCD3700 [16/39] Sleeping function

PIP function is “OFF” PIP function is “ON”

“##” is the number of current PIP channel. “- - - -” is the name of the PIP channel (at most 7 letters), if the

channel name is not changed, “----” will be displayed, “AUTO/DK” is the current PIP TV color/sound mode.

“XX” means the name of current signal COMP1, COMP2, HDMI or HDMI2.

In VGA, or HDMI or HDMI2 mode, the resolution of the picture is displayed (NO SIGNAL will be dis-

played if there is no signal input), the color mode (also the sound mode) will no longer be displayed, when

the input signal is 1024*768/60Hz, the information displayed is as following picture:

PIP function is “OFF” PIP function is “ON”

“##” is the number of current PIP channel. “- - - -” is the name of the PIP channel (at most 7 letters), if the

channel name is not changed, “----” will be displayed, “AUTO” is the current PIP TV color/sound mode.

“XX” means the name of current signal VGA, HDMI or HDMI 2.

Sleeping Function

Press SLEEP button on the RC, the following picture will be displayed on the screen:

Press SLEEP button on the RC repeatedly to change the time for turning off the TV, the following will be

displayed in cycle: Off, 15, 30, 45, 60, 90 and 120, if the current display is “OFF”, this mean there is no tim-

ing operation for turning off the TV, any other value displayed (e.g. 15) means that after 15 minutes since the

current time, the system will execute the turning off operation, meanwhile, the mode indicator lighting

green/red in turns (10 seconds for green light, and then after green light extinguished the red light will be on

for 5 second, green light and red light are on and off in turn)

After starting the Sleep timing function, press SLEEP button on the RC, the time remained will be displayed,

if press this button again, the timing can be reset among Off, 15, 30, 45, 60, 90 and 120.

The following information will be displayed 30 seconds before the TV enter into SLEEP mode:

System will power down

Press OK to cancel

“xx” is the remained number which indicates you with how many seconds the TV will enter into SLEEP

mode. The value will be deducted to 0 from 30. At this time, you can press OK button on the RC to quit the

SLEEP mode.

Standby Function When No Signal Input

When there is no any signal input, the LCD TV will turn to blue or black screen mode automatically (TV

lower noise point), if there is no any operation to the LCD TV within 5 minutes, LCD TV will enter into

standby mode automatically.

30 seconds before the TV entering into standby mode, the indication information will be displayed in the up-

per right position on the screen is as following:

COMP2 720P/60Hz

TIME

## AUTO

--------

COMP1 720P/60Hz

TIME

XX 1024*768/60Hz

TIME

XX 1024*768/60Hz

TIME

## AUTO

--------
