Page 6
Installation Overview
3
Unit Installation
Overview
L N
1
2
3
4
5
MC MC
6
7
Install the indoor unit
(Page 7)
INSTALLATION ORDER
Install the outdoor unit
(Page 12)
Install the drainpipe
(Page 15)
Evacuate the refrigeration
system
(Page 24)
Connect the wires
(Page 20)
Connect the refrigerant
pipes
(Page 17)
Perform a test run
(Page 26)
