Tp-Link Archer MR200 V2 [2/2] Customize the 4g lte router led indicators

Tp-Link Archer MR200 V2 [2/2] Customize the 4g lte router led indicators
Customize the 4G LTE Router LED Indicators
LED Status Indication
O
On
On/O
Flashing
O
On
O
On
O
On
O
On
(Wireless)
(WPS)
(LAN)
(Internet)
(Power)
On
Flashing
O
The system has started up successfully.
The system is starting up or firmware is being upgraded. Do not
disconnect or power off your router.
Power is off.
The router is connected to the internet.
There is no internet connection.
The router is connected to the 4G network.
The router is disconnected from the 4G network.
At least one wireless radio band (2.4 GHz or 5 GHz) is enabled.
The wireless radio band is disabled.
At least one LAN port is connected to a powered-on device.
No LAN port is connected to a powered-on device.
This light remains on for 5 minutes when a WPS connection is
established, then turns o.
WPS connection is in progress. This may take up to 2 minutes.
Indicates the signal strength received from the mobile internet
network. More lit bars indicate a better signal strength.
There is no mobile internet signal.
(4G)
(Signal
Strength)
Note: If the login page does not appear, please refer to FAQ > Q1.
http://tplinkmodem.net
HighMiddleLow
Save
Confirm Password
New Password
1. Make sure your computer is connected to the router (via wired or
wireless).
2. Launch a web browser and type in http://tplinkmodem.net or
192.168.1.1. Create a new password (1-15 characters) and click Save.
Note: For subsequent logins, use your password that you have created.
3. Enter the new password that you created and click Log in.
Note: The router can also be used (or configured) in Wireless Router Mode for ADSL/Cable
connections. For more advanced configurations, please refer to the User Guide on TP-Link
official website at www.tp-link.com.
Next
Back
Wireless Network (2.4GHz):
Password:
TP-Link_XXXX
XXXXXXXX
Wireless Network Name (SSID):
Enable
Wireless Network (5GHz):
Password:
TP-Link_XXXX_5G
XXXXXXXX
Wireless Network Name (SSID):
Enable
4. Follow the step-by-step instructions of the Quick Setup to complete
the initial conguration. On the Wireless Settings page, you can
customize your 2.4GHz and 5GHz wireless network names and
passwords.
©2017 TP-Link
7106507085 REV2.0.0
To manage your network conveniently on your mobile
device, scan the QR code to download the Tether App.
Tether App
FAQ (Frequently Asked Questions)
WPS/RESET Button
Press and hold until the Power LED starts ashing
Q1. What should I do if I cannot access the web management page?
A1. If the computer is set to a static IP address, change its settings to obtain an IP
address automatically.
A2. Make sure http://tplinkmodem.net or http://192.168.1.1 is correctly entered in the
web browser.
A3. Use another web browser and try again.
A4. Reboot your router and try again.
A5. Disable and enable the active network adapter in use.
Q2. What should I do if I cannot access the internet?
A1. Verify that your SIM card is an LTE, WCDMA or GSM card.
A2. Verify that your SIM card is in your internet service provider’s service area.
A3. Verify that your SIM card has sucient credit.
A4. Check the LAN connection:
Open a web browser and enter http://tplinkmodem.net or http://192.168.1.1 in the
address bar. If the login page does not appear, refer to FAQ > Q1 and then try
again.
A5. Check your ISP parameters:
1) Open a web browser and log in to the web management page.
2) Go to Advanced > Network > Internet to verify the parameters (including the APN,
Username and Password) provided by your ISP are correctly entered. If the parameters
are incorrect, click Create Prole and enter the correct parameters, then select the new
prole from the Prole Name list.
A6. Check the PIN settings:
1) Open a web browser and log in to the web management page.
2) Go to Advanced > Network > PIN Management to verify if PIN is required. If it is, enter
the correct PIN provided by your ISP, and click Apply.
A7. Check the Data Limit:
1) Open a web browser and log in to the web management page.
2) Go to Advanced > Network > Data Settings to verify if the Total/Monthly Used exceeds
the Total/Monthly Allowance. If it does, click Correct and set Total/Monthly Used to 0
(zero), or disable Data Limit.
A8. Check the Mobile Data:
1) Open a web browser and log in to the web management page.
2) Go to Advanced > Network > Internet to verify that Mobile Data is enabled. If it is not,
enable it to access the internet.
A9. Check the Data Roaming:
1) Conrm with your ISP if you are in a roaming service area. If you are, open a web
browser and log in to the web management page.
2) Go to Advanced > Network > Internet to enable Mobile Roaming.
Q3. How do I restore the router to its factory default settings?
A1. With the router powered on, press and hold
the WPS/RESET button on the rear panel of
the router until the Power LED starts ashing,
then release the button. Wait while the router
resets.
A2. Log in to the web management page of the
router, and go to Advanced > System Tools >
Backup & Restore, click
Factory Restore and
wait until the reset process is complete.
Q4. What should I do if I forget my web management page password?
A. Refer to FAQ > Q3 to reset the router, and then set a new password using 1-15
characters.
Q5. What should I do if I forget my wireless network password?
A1. The default Wireless Password is printed on the product label of the router.
A2. If the default Wireless Password has been changed, log in to the router's web
management page and go to Basic > Wireless to retrieve or reset your password.
For technical support and other information, please visit
http://www.tp-link.com/support
