Tp-Link RE365 V1 [9/49] Quick setup
![Tp-Link RE365 V1 [9/49] Quick setup](/views2/1469441/page9/bg9.png)
6
Chapter 2
Set Up Internet Connection
2. 1. Quick Setup
Power on
Plug the extender into an electrical outlet next to your host router, and then wait until
the Power LED is solid on.
Note: For safety, we suggest that you plug the extender in upright directions as shown below.
Power
Power
LED
5GHz
2.4GHz
Ethernet
Power
On
Connect to the host network
There are three ways to connect to the host network: via a web browser, via the Tether
app, and via the WPS button.
2. 1. 1. Method 1: Via a Web Browser
1. Connect your computer to the extender's wireless network.
Tips:
Before connecting, please find the SSID (network name) on the label of the extender.
• For Windows Users
1 ) Unplug the Ethernet cable from your computer (if any).
2 ) Click the Wi-Fi icon on the taskbar and connect to the extender’s wireless
network: TP-Link_Extender_2.4GHz or TP-Link_Extender_5GHz.
