Camera Control for Windows

 Device List:

 Added Devices: Displays the cameras added to your account. The camera will be

marked red if it is disconnected from your local network.

 New Devices: Displays the cameras ready to be added. The system can automatically

discover the cameras newly connected to your local network. You can double-click them

or drag them to the Added Devices list to add them.



: Click to choose a layout for displaying cameras. The system can display one, four, six,

or nine cameras on each page.



: Click to take a snapshot of the camera(s) you select. To view the snapshots you take,

click the Playback tab and find them by Camera name/MAC → Date.



/ : Click to take a video record of the camera(s) you select. To view the video

records you take, click the Playback tab and find them by Camera name/MAC → Date.



/ : Click to switch to the previous/next page if there are multiple pages.



: Click to set a cycle duration for auto-switching pages. The system can auto-switch

pages every 20

seconds, 30 seconds, 1 minute, 3 minutes, or 5 minutes. This function is

turned off by default.



: Click to enter the full screen mode. To exit this mode, press Esc on your keyboard.

Single-camera monitoring

You can double-click the view of a camera to enter/exit single-camera monitoring.

Brightness

Contrast

Saturation

Preset

Layout

back

Flip/

Mirror

Audio
