- 11 - Hardware Installation
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
2 x USB 2.0/1.1 headers
1 x serial port header
1 x clearing CMOS jumper
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x D-Sub port
1 x DVI-D port
1 x HDMI port
4 x USB 2.0/1.1 ports
2 x USB 3.0/2.0 ports
1 x RJ-45 port
3 x audio jacks (Line In/Line Out/Microphone)
I/O Controller iTE IT8720 chip
Hardware
Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan fail warning
CPU/System fan speed control
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.
Содержание
- 1 1 configuring the onboard sata controller 1
- 1 2 installing the sata raid ahci driver and operating system 1
- 1 configuring sata hard drive s 1
- 1 installation precautions 1
- 1 installing chipset drivers 1
- 1 startup screen 1
- 1 xpress recovery2 1
- 10 load fail safe defaults 1
- 11 load optimized defaults 1
- 12 set supervisor user password 1
- 13 save exit setup 1
- 14 exit without saving 1
- 2 1 configuring 2 4 5 7 channel audio 1
- 2 1 updating the bios with the q flash utility 1
- 2 2 configuring microphone recording 1
- 2 2 updating the bios with the bios utility 1
- 2 3 using the sound recorder 1
- 2 application software 1
- 2 bios update utilities 1
- 2 configuring audio input and output 1
- 2 product specifications 1
- 2 the main menu 1
- 3 1 frequently asked questions 1
- 3 1 installing the cpu 1
- 3 2 installing the cpu cooler 1
- 3 2 troubleshooting procedure 1
- 3 easytune 6 1
- 3 installing the cpu and cpu cooler 1
- 3 mb intelligent tweaker m i t 1
- 3 technical manuals 1
- 3 troubleshooting 1
- 4 1 dual channel memory configuration 1
- 4 2 installing a memory 1
- 4 contact 1
- 4 installing the memory 1
- 4 q share 1
- 4 standard cmos features 1
- 5 advanced bios features 1
- 5 installing an expansion card 1
- 5 smart recovery 1
- 5 system 1
- 6 auto green 1
- 6 download center 1
- 6 integrated peripherals 1
- 6 setup of the ati hybrid crossfirex configuration 1
- 7 back panel connectors 1
- 7 cloud oc 1
- 7 new utilities 1
- 7 power management setup 1
- 8 internal connectors 1
- 8 pnp pci configurations 1
- 9 pc health status 1
- Chapter 1 hardware installation 1
- Chapter 2 bios setup 1
- Chapter 3 drivers installation 1
- Chapter 4 unique features 1
- Chapter 5 appendix 1
- Ga 880gm usb3l 1
- User s manual 1
- Ga 880gm usb3l 2
- Mar 1 2011 2
- Motherboard 2
- Copyright 3
- Disclaimer 3
- Documentation classifications 3
- Identifying your motherboard revision 3
- Box contents optional items 4
- Chapter 1 hardware installation 4
- Chapter 2 bios setup 0 4
- Ga 880gm usb3l motherboard layout ga 880gm usb3l motherboard block diagram 4
- Table of contents 4
- Chapter 3 drivers installation 6 5
- Chapter 4 unique features 0 5
- Chapter 5 appendix 2 5
- Box contents 6
- Optional items 6
- Ga 880gm usb3l 7
- Ga 880gm usb3l motherboard layout 7
- Ga 880gm usb3l motherboard block diagram 8
- 1 installation precautions 9
- Chapter 1 hardware installation 9
- 2 product specifications 10
- 3 1 installing the cpu 13
- 3 installing the cpu and cpu cooler 13
- 3 2 installing the cpu cooler 15
- 4 1 dual channel memory configuration 16
- 4 installing the memory 16
- 4 2 installing a memory 17
- 5 installing an expansion card 18
- 6 setup of the ati hybrid crossfire 19
- A system requirements 19
- B connecting the graphics cards 19
- C bios setup 19
- Configuration 19
- D configuring the graphics driver 19
- 7 back panel connectors 20
- D sub port 20
- Dvi d por 20
- Hdmi por 20
- Ps 2 keyboard mouse port 20
- Usb 2 1 port 20
- A dual display configurations 21
- B playback of hd dvd and blu ray discs 21
- Line in jack blue 21
- Line out jack green 21
- Mic in jack pink 21
- Rj 45 lan port 21
- Usb 3 2 port 21
- 8 internal connectors 22
- 2 atx_12v atx 2x2 12v power connector and 2x12 main power connector 23
- 23 hardware installation 23
- To meet expansion requirements it is recommended that a power supply that can withstand to meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system 23
- With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector first make sure the power supply is turned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation the 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 23
- 4 cpu_fan sys_fan fan headers 24
- Clr_cmos clearing cmos jumper 24
- 25 hardware installation 25
- A raid 0 or raid 1 configuration requires at least two hard 25
- A raid 10 configuration requires four hard drives 25
- Always turn off your computer and unplug the power cord before replacing the battery replace the battery with an equivalent one danger of explosion if the battery is replaced with 25
- An incorrect model 25
- Bat battery 25
- Contact the place of purchase or local dealer if you are not able to replace the battery by your 25
- Drives if more than two hard drives are to be used the total number of hard drives must be an even number 25
- Of the battery the positive side should face up 25
- Sata2_0 1 2 3 sata 3gb s connectors 25
- Self or uncertain about the battery model 25
- The battery provides power to keep the values such as bios configurations date and time information in the cmos when the computer is turned off replace the battery when the battery voltage drops to a low level or the cmos values may not be accurate or may be lost 25
- The sata connectors conform to sata 3gb s standard and are compatible with sata 1 gb s standard each sata connector supports a single sata device the amd sb710 controller supports raid 0 raid 1 raid 10 and jbod refer to chapter 5 configuring sata hard drive s for instructions on configur ing a raid array 25
- Used batteries must be handled in accordance with local environmental regulations 25
- When installing the battery note the orientation of the positive side and the negative side 25
- F_panel front panel header 26
- 27 hardware installation 27
- Audio signals will be present on both of the front and back panel audio connections simultane 27
- F_audio front panel audio header 27
- Front panel audio module refer to the instructions on how to activate ac 97 functionality via the audio software in chapter 5 configuring 2 4 5 7 channel audio 27
- Instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer 27
- Ously if you want to mute the back panel audio only supported when using an hd front panel audio module refer to chapter 5 configuring 2 4 5 7 channel audio 27
- Some chassis provide a front panel audio module that has separated connectors on each wire 27
- Spdif_o s pdif out header 27
- The front panel audio header supports hd audio by default if your chassis provides an ac 97 27
- The front panel audio header supports intel high definition audio hd and ac 97 audio you may connect your chassis front panel audio module to this header make sure the wire assignments of the module con nector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it 27
- This header supports digital s pdif out and connects a s pdif digital audio cable provided by expan sion cards for digital audio output from your motherboard to certain expansion cards like graphics cards and sound cards for example some graphics cards may require you to use a s pdif digital audio cable for digital audio output from your motherboard to your graphics card if you wish to connect an hdmi display to the graphics card and have digital audio output from the hdmi display at the same time for information about connecting the s pdif digital audio cable carefully read the manual for your expan sion card 27
- Com serial port header 28
- Cord from the power outlet to prevent damage to the usb bracket 28
- Do not plug the ieee 1394 bracket 2x5 pin cable into the usb header prior to installing the usb bracket be sure to turn off your computer and unplug the power 28
- F_usb1 f_usb2 usb headers 28
- Hardware installation 28 28
- The com header can provide one serial port via an optional com port cable for purchasing the op tional com port cable please contact the local dealer 28
- The headers conform to usb 2 1 specification each usb header can provide two usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer 28
- Chapter 2 bios setup 29
