Tp-Link TL-ANT2410MO V1 [4/12] Introduction
![Tp-Link TL-ANT2410MO V1 [4/12] Introduction](/views2/1470618/page4/bg4.png)
Introduction
The TL-ANT2410MO, 2.4GHz 10dBi 2x2 MIMO Omni Antenna,
can be used together with the outdoor wireless Base Station
WBS210 to achieve a stable omnidirectional signal transmission.
Specications
Electrical Specifications TL-ANT2410MO
Frequency Range
Gain
VSWR
HPOL Beamwidth
VPOL Beamwidth
Elevation Beamwidth
Electrical Downtilt
F/B Ratio
Polarization
Impedance
Connector
2.35 to 2.55GHz
10dBi
1.85 Max
360°
360°
13°
4°
24dB Min
Horizontal & Vertical
50Ω
RP-SMA Female
Antenna Dimension
Weight
Rated Wind Velocity
Mounting
Φ76×800mm
2.0Kg
241Km/h
Pole Mount
Mechanical Specifications
1
