![Tp-Link T2600G-28MPS V4 [7/24] T2500g 10mps t2600g 28mps has an led mode switch button which is used to switch the led status indication when the speed led is on the port led is indicating the data transmission rate when the poe led is on the port led is indicating the power supply status by default the speed led is on pressing the mode switch button the speed led will turn off and the poe led will light up then the poe led will turn off after being on for 60 seconds and the speed led will light up again](/views2/1470621/page7/bg7.png)
JetStream L2 Managed Switch
04Introduction
LED Indication
1000M
10/100/1000M
10/100/1000BASE-T
Green On: Running at 1000Mbps, but no activity.
Green Flashing: Running at 1000Mbps and is transmitting or receiving data.
Yellow On: Running at 10/100Mbps, but no activity.
Yellow Flashing: Running at 10/100Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: 1000M for T2500-28TC, 10/100/1000M for T2500G-10TS, 10/100/1000Base-T
for TL-SG5412F and the 48 LEDs above the RJ45 ports for T2600G-52TS.
1000Mbps
On: Running at 1000Mbps.
Off: Running at 10/100Mbps or no device is linked to the corresponding port.
Note: For TL-SG5412F/T2600G-18TS/T2600G-28TS/T2600G-28SQ.
Link/Act
On: A device is linked to the corresponding port and running properly.
Flashing: Transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: For TL-SG5412F/T2600G-18TS/ T2600G-28TS/T2600G-52TS and ports 1-24
of T2600G-28SQ.
Link/Act
Green On: Running at 10Gbps, but no activity.
Green Flashing: Running at 10Gbps and is transmitting or receiving data.
Yellow On: Running at 1000Mbps, but no activity.
Yellow Flashing: Running at 1000Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: Only for ports 25-28 of T2600G-28SQ.
SFP1, SFP2
On
: A device is linked to the corresponding port.
Flashing
: The corresponding SFP port is transmitting or receiving data.
Off
:
No device is linked to the corresponding SFP port.
Note: Only for T2500G-10TS.
T2500G-10MPS/T2600G-28MPS has an LED mode switch button which is used to switch the LED
status indication. When the Speed LED is on, the port LED is indicating the data transmission rate.
When the PoE LED is on, the port LED is indicating the power supply status. By default the Speed LED
is on. Pressing the mode switch button, the Speed LED will turn off and the PoE LED will light up. Then
the PoE LED will turn off after being on for 60 seconds and the Speed LED will light up again.
LED Indication
PWR
On: The switch is powered on.
Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal.
SYS
Flashing: The switch works properly.
On or Off: The switch works improperly.
FAN
Green: All the fans work properly.
Yellow: Not all the fans work properly.
Off: The switch works improperly.
