MOUNTING AND OPERATION
Action Figure Page
Fixing and removing side handle
1 114
Fixing and removing side handle and
handle joint
2 114
Mounting and dismounting the bit 3 114
Dismounting the bit (When the drill
chuck cannot be loosened)
4 115
Selecting rotational direction 5 115
Switch operation 6 115
Locking-on the switch 7 115
Releasing the switch 8 115
Dismounting drill chuck from tool 9 115
Mounting angle attachment (Optional
accessory)
10 116
Selecting speed of angle attachment 11 116
Dismounting drill chuck from angle
attachment
12 116
Fixing side handle for angle attachment
13 116
Mounting position of hook (A)*
1
(Optional accessory)
14 116
Selecting accessories ― 117
*1 Attaching the hook. (Optional accessory)
To attach the hook, it is necessary to disassemble the
handle portion which covered the tool’s electrical system.
For your continued safety and electrical shock protection,
installing the hook on this drill should ONLY be performed
by a HiKOKI AUTHORIZED SERVICE CENTER.
Selecting the appropriate drill bit
○ When boring metal or plastic
Use ordinary metalworking drill bits.
Sizes range from a minimum of 1.2 mm to chuck
maximum capacity.
○ When boring wood
Use ordinary woodworking drill bits.
However, when drilling 6.5 mm or smaller holes, use a
metalworking drill bit.
MAINTENANCE AND INSPECTION
1. Inspecting the drill bits
Since use of an abraded drill bits will cause motor
malfunctioning and degraded effi ciency, replace the drill
bits with a new one or resharpening without delay when
abrasion is noted.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
3. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool. Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
4. Inspecting the carbon brushes
For your continued safety and electrical shock protection,
carbon brush inspection and replacement on this tool
should ONLY be performed by a HiKOKI Authorized
Service Center.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
GUARANTEE
We guarantee HiKOKI power tools in accordance with
statutory/country specifi c regulation. This guarantee does
not cover defects or damage due to misuse, abuse, or
normal wear and tear. In case of complaint, please send
the power tool, undismantled, with the GUARANTEE
CERTIFICATE
found at the end of this Handling instruction,
to a HiKOKI Authorized Service Center.
IMPORTANT
Correct connection of the plug
The wires of the main lead are coloured in accordance with
the following code:
Blue: — Neutral
Brown: — Live
As the colours of the wires in the main lead of this tool may
not correspond with the coloured markings identifying the
terminals in your plug proceed as follows:
The wire coloured blue must be connected to the terminal
marked with the letter N or coloured black. The wire
coloured brown must be connected to the terminal marked
with the letter L or coloured red. Neither core must be
connected to the each terminal.
NOTE:
This requirement is provided according to BRITISH
STANDARD 2769: 1984.
Therefore, the letter code and colour code may not be
applicable to other markets except The United Kingdom.
Information concerning airborne noise and vibration
The measured values were determined according to
EN60745 and declared in accordance with ISO 4871.
Measured A-weighted sound power level: 91 dB (A).
Measured A-weighted sound pressure level: 84 dB (A).
Uncertainty K: 3 dB (A).
Wear hearing protection.
Vibration total values (triax vector sum) determined
according to EN60745.
Drilling into metal:
Vibration emission value a
h
, D = 1.7 m/s
2
Uncertainty K = 1.5 m/s
2
The declared vibration total value has been measured in
accordance with a standard test method and may be used
for comparing one tool with another.
It may also be used in a preliminary assessment of exposure.
WARNING
○ The vibration emission during actual use of the power
tool can diff er from the declared total value depending in
the ways in which the tool is used.
○ Identify safety measures to protect the operator that
are based on an estimation of exposure in the actual
conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is
switched off and when it is running idle in addition to the
trigger time).
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
