Hardware Installation - 10 -
1-2 ProductSpecications
CPU
Support for AM3 processors:
AMD Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport Bus
5200 MT/s
Chipset
North Bridge: AMD 870
South Bridge: AMD SB850
Memory
4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
(Note 1)
Dual channel memory architecture
Support for DDR3 1866(O.C.)/1333/1066 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Audio
Realtek ALC892 codec
High Denition Audio
2/4/5.1/7.1-channel
Support for Dolby
®
Home Theater
Support for S/PDIF In/Out
Support for CD In
LAN
1 x Realtek RTL8111D/E chip (10/100/1000 Mbit)
Expansion Slots
1 x PCI Express x16 slot, running at x16 (PCIEX16)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
(Note 2)
2 x PCI Express x1 slots (The PCIEX1_1 and PCIEX1_2 slots share bandwidth
with the PCIEX4 slot.)
(Note 2)
(All PCI Express slots conform to the PCI Express 2.0)
3 x PCI slots
Storage Interface
South Bridge:
- 6 x SATA 6Gb/s connectors (SATA3_0~SATA3_5) supporting up to 6 SATA
6Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
GIGABYTE SATA2 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 2 x SATA 3Gb/s connectors (GSATA2_6, GSATA2_7) supporting up to 2
SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1 and JBOD
JMicron JMB362 chip:
- 2 x eSATA 3Gb/s connectors on the back panel supporting up to 2 SATA
3Gb/s devices
- Support for SATA RAID 0, RAID 1, and JBOD
iTE IT8720 chip:
- 1 x oppy disk drive connector supporting up to 1 oppy disk drive
